When you order parts, please make a photocopy of this page
and fill the number of the parts in the “Order” column.
Ref. No. Ref. No.Description Description
Ord.
Q’ty
Ord.
Q’ty
IC1 IC µPD780023CW-035 9702969028
IC2 IC NJM7805FA 0100462081
IC3,4 Transistor Array µPA2003GR 0100028041
IC6 IC PST600CMTR 0101461120
IC7,8 IC HU2001 9701651016
IC10 IC NM93C46M8-X 0101622026
Q1,2 Xstr 2SD1932 9701235018
Q3 Xstr DTC-124EKA 0000936033
Q4~8 Xstr 2SC2712 0000781053
D1,2 Diode D2SB20 0000599023
D3 Diode MTZJ15A 0000852081
D4 Diode MTZJ27A 0000852098
D5,12 Diode D1F60 0000208024
D6,7 Diode DA226U 0000625036
D8~10,15~17 Diode SLR-325VC 0000813259
D11,13 Diode DAN202K 0000684019
R1,9,10,37~40, Res. 1/10W 10kΩ±5% 0200213019
43,44,46~50,
56~58
R2~6 Res. 1/10W 4.7kΩ±5% 0200212906
R7,8,11~15 Res. 1/10W 1kΩ±5% 0200212746
30~33,
51~55
R17 Res. 1/10W 38.3kΩ±1% 0201114575
R18,19 Res. 1/10W 14kΩ±1% 0201114193
R20,21 Res. 1/10W 6.65kΩ±1% 0201113806
R23~25,34~36 Res. 1/10W 390kΩ±5% 0200212647
R41,42 Res. 1/4W 15kΩ±5% 0200231051
R45 Res. 1/4W 10kΩ±5% 0200231013
R59~66 Res. 1/4W 10Ω±5% 0200230269
CJ28,35,37 Res. 0Ω 0200212012
C1 Cap. Plastic 0.22µF 0300304099
C3,4 Cap. Ceramic 0.1µF 0300209127
C5 Cap. Elec. 50V 3300µF 0301190998
C6 Cap. Elec. 63V 2200µF 0301191117
C7~9 Cap. Elec. 50V 10µF 0301192541
C10,47 Cap. Elec. 50V 100µF 0301192589
C11 Cap. Elec. 25V 1000µF 0301190615
C12,13,17~21, Cap. Ceramic. 50V 0.1µF 0300311752
36,43~46
C14,38~41 Cap. Ceramic. 50V 0.01µF 0300311738
C15,16,23~26, Cap. Ceramic. 50V 1000pF 0300308509
CJ27
C29~33 Cap. Elec. 25V 10µF 0300822340
X1 Ceramic Resonator 9701261017
EF0EC8384T4
K1,2,5,6 Relay JQ1-12V 9701316014
CR1~3 CR Absorber RPEL-121204 9701125012
VA1,2 Varistor TNR12G471K 0000038010
SA1 Arrester RA-362M-V7-F 0600280154
F1 Fuse BET 3.15A-250V 0600239534
FH 1,2 Fuse Holder PFC5000-0502 0500158072
HT1 Heat Sink PUG-46 9702966010
HT2 Heat Sink B.PUE-16 9701376018
CN1 Plug. PCB B2P3-VH-B-C 0500011773
CN2 Plug. PCB B2P3-VH-B-Y 0500011827
CN3 Plug. PCB B4P7-VH-B 0500011742
CN4 Plug. PCB 179844-1 0501121013
CN5 Plug. PCB 179844-2 0501121020
CN7 Plug. PCB B2P3-VH-B 0500011728
CN8 Plug. PCB B4B-XH-AM 0500005314
CN9 Plug. PCB B10B-XASK-1-A 0501045098
CN10 Plug. PCB B3B-XASK-1-A 0501045029
CN11 Plug. PCB B6B-XASK-1-A 0501045050
CN12 Plug. PCB B6B-XASK-1-A 0501045418
CN14 Plug. PCB B5P-SHF-1AA 0500006069
CN18 Plug. PCB B3B-XARK-1-A 0501045319
E Wire w/Terminal L=100mm GRN 9702313012
W1 Wire w/Terminal L=330mm RED 9703932021
W2 Wire w/Terminal L=380mm PNK 9703932014
Part No. Part No.
OUTDOOR PCB
CONTROLLER PCB ASSEMBLY (Ref. No. 236)
AOU18RD
– 19 –
