OUTLINE AND DIMENSIONS
INDOOR UNIT
Unit : inch (mm)
39-1/8" (990)
900
19-3/4" (500)
25-7/8" (655)
530
200175
7-7/8" (199)
(rear view)
22005.12.21
Models :
ABU18RULX, ABU24RULX
