PARTS
OUTDOOR UNIT
2012.12.21 18
3 Top Panel Assy 9318464023
4 Front Panel Assy 9318463026
6
7
Cabinet Left Assy 9318461015
5 Emblem 9317903011
Switch Cover 9317692021
8 Cabinet Right Assy 9316044050
11 Propeller Fan 9313808013
9 Reactor Assy 9900611019
10 Fan Motor 9602724017
Ref. Description Part number
2 Protective Net
1 Thermistor Holder 9313954031
9332492002
4
5
6
9
11
10
7
8
3
2
1
