Fujitsu AOU9RLS2H Service Manual
4
of 1
of 1 rating
23 pages
Give review
Manual
Specs
To Next Page
To Next Page
To Previous Page
To Previous Page
Loading...
DIMENSIONS
unit : inch (mm)
11-3/32 (282)
7-9/32 (185)
34-1/4 (870)
2012.07.19
2
INDOOR UNIT
OUTDOOR UNIT
Drain pipe diameter
16.2 mm
Liquid pipe diameter : 1/4 inch (6.35 mm)
Gas pipe diameter : 3/8 inch (9.52 mm)
11-13/32 (290)
31-3/32 (790)
21-1/4 (540)
24-13/32 (620)
2
4
Table of Contents
Table of Contents
1
Wall Mounted Type
1
Indoor Unit
1
Specifications
2
Dimensions
3
Refrigerant System Diagram
4
Circuit Diagram
5
Indoor Pcb Circuit Diagram
6
Outdoor Pcb Circuit Diagram
10
Indoor Unit Remote Control
12
Error Detection
12
Parts (Indoor Unit)
14
Parts (Outdoor Unit)
19
Accessories
22
