WALL MOUNTED TYPE ASU9-15RLS2 WALL MOUNTED TYPE ASU9-15RLS2
SPECIFICATIONS3.
Note :
Specications are based on the following conditions.
Cooling : Indoor temperature of 80°F (26.67°C) DB / 67°F (19.44°C) WB, and outdoor temperature of 95°F (35°C) DB / 75°F (23.9°C) WB.
Heating : Indoor temperature of 70°F (21.11°C) DB / 59°F (15°C) WB, and outdoor temperature of 47°F (8.33°C) DB / 43°F (6.11°C) WB.
Pipe length : 24ft.7in (7.5m), Height difference:0 m. (Outdoor unit-Indoor unit)
The protective function might work when using it outside the operation range.
*: The maximum current is the maximum value when operated within the operation range.
Type
WALL MOUNTED
INVERTER HEAT PUMP
Model name ASU9RLS2 ASU12RLS2 ASU15RLS2
Power source 208 / 230V ~ 60Hz
Available boltage range 187 - 253V ~ 60Hz
Capacity
Cooling
Rated
kW 2.64 3.52 4.25
Btu/h 9000 12000 14500
Min - Max
kW 0.90 - 3.60 0.90 - 4.00 0.90 - 5.40
Btu/h 3100 - 12000 3100 - 13600 3100 - 18400
Heating
Rated
kW 3.52 4.69 5.28
Btu/h 12000 16000 18000
Min - Max
kW 0.90 - 6.45 0.90 - 6.50 0.90 - 7.00
Btu/h 3100 - 22000 3100 - 22100 3100 - 23900
Input power
Cooling
Rated
kW
0.56 0.87 1.21
Max 0.90 1.08 1.93
Heating
Rated 0.80 1.20 1.35
Max 1.99 2.00 2.26
Current
Cooling
Rated A
2.7 4.0 5.5
Heating 3.7 5.5 6.1
EER Cooling
kW/kW 4.71 4.05 3.51
Btu/hW 16.1 13.8 12.0
COP Heating
kW/kW 4.40 3.91 3.91
Btu/hW 15.0 13.3 13.3
SEER Cooling Btu/hW 27.2 25.0 21.5
HSPF Heating Btu/hW 8.8 9.3 10.3
Power factor
Cooling
%
90 95 96
Heating 94 95 96
Moisture removal pints/h (l/h) 2.7 (1.3) 3.8 (1.8) 4.4 (2.1)
Maximum operating current *
Cooling
A
9.4 9.4 9.9
Heating 11. 9 11. 9 14.9
Fan
Airow rate
Cooling
High
CFM
(m
3
/h)
500 (850) 529 (900)
Med 394 (670) 435 (740)
Low 324 (550) 335 (570)
Quiet 194 (330) 229 (390)
Heating
High 500 (850) 559 (950)
Med 418 (710) 435 (740)
Low 324 (550) 353 (600)
Quiet 194 (330) 253 (430)
Type × Q'ty Cross ow fan × 1
Motor output W 29
Sound pressure level
Cooling
High
dB (A)
43 45
Med 37 40
Low 32 33
Quiet 21 25
Heating
High 43 45
Med 38 40
Low 32 34
Quiet 21 27
Heat exchanger type
Dimensions
(H × W × D)
in. (mm)
Main : 12-19/32 × 27-5/32 × 25/32 (320 × 690 × 20)
Sub : 3-5/16 × 27-5/32 × 17/32 (84 × 690 × 13.3)
Fin pitch FPI Main : 23 Sub : 18
Rows × Stages Main : 2 × 20 Sub : 1 × 4
Pipe type Copper
Fin type Aluminum
Enclosure
Material Polystyrene
Color
White
Approximate color of MUNSELL N9.3/
Dimensions
(H × W × D)
Net
inch 11 - 3/32 × 34 - 1/4 × 7 - 9/32
mm 282 × 870 × 185
Gross
inch 9 - 23/32 × 36 - 7/32 × 14 - 11/16
mm 247 × 920 × 373
Weight
Net
lbs. (kg)
21 (9.5)
Gross 27 (12)
Connection pipe
Size
Liquid
in. (mm)
Ø1/4 (Ø6.35)
Gas Ø3/8 (9.52) Ø1/2 (12.7)
Method Flare
Operation range
Cooling
°F (°C) 64 to 90 (18 to 32)
%RH 80 or less
Heating °F (°C) 60 to 88 (16 to 30)
Remote controller type Wireless
Drain hose
Material PE
Size in.(mm)
Ø17/32 (Ø13.8) (I.D.)
Ø5/8 to Ø21/32 (Ø15.8 to Ø16.7) (O.D.)
