JP (Jumper) Setting
[Indoor Unit]
AS*9/12LSACW
AS*9/12LSBCW
AS*14/18LSBCW
Remote control custom code
When multiple number of indoor units are installed in the same room, erroneous receipt of the signal can
be avoided by setting up the remote control custom code separately.
To set up the remote control custom code, always set up the same code on both indoor unit PCB and
remote control PCB.
(When the indoor unit PCB is changed to Code B, it can not receive the signal unless remote control PCB
is also changed to Code B.)
Indoor Unit Remote Control
JM1(JP)
D4 (Diode)
Code A (Default)
Code B
Auto Restart
It is possible to disengage Auto Restart function if it is not needed.
Indoor Unit
JM2 (JP)
With Auto Restart function
(Default)
YES
Without Auto Restart
function
NO
[Outdoor Unit]
AO*9/12LSAC
JP
JM101 JM102 JM103 JM104 JM105 JM106 JM107
Normal Preheat
NO
NO NO
NO
NO
YES
NO
9LSAC
Higher Preheat
NO NO NO
YES
NO NO NO
Normal Preheat
NO
YES
NO NO NO NO NO
12LSAC
Higher Preheat
NO
NO
NO NO NO NO NO
AO*9/12LFBC
JP
JM500
Normal Preheat YES
Higher Preheat NO
AO*14/18LFBC
JP
JM101 JM102 JM103 JM104 JM105 JM106 JM107
Normal Preheat
NO YES
NO NO NO NO NO
14LSBC
Higher Preheat
NO
NO
NO NO NO NO NO
Normal Preheat
NO NO NO NO NO
YES
NO
18LSBC
Higher Preheat
NO
NO NO
YES
NO NO NO
- it is possible to select the higher or standard level of preheating function.
- When it is set up at the higher level of preheat, the magnetic noise of the compressor becomes higher.
08-01
AR-JE (LSAC)
X
X
D3 (Diode)
AR-NJ (LSBC)
X
*
*
