Fujitsu AOY54APA3L User Manual

2003.06.11
- 22 -
When you order parts, please make a photocopy of this page
and fill the number of the parts in the "Order" column.
INDOOR UNIT (Continued)
AUT54RLB3WAUG54RLB3W AUY54ALB3W AUY54RLB3W AUT54ALB3W
488 Drain Pan Plug 313005174654 313005174654 313005174654 313005174654 313005174654 313005174654
514 Control Box Cover 9362763004 9362763004 9362763004 9362763004 9362763004 9362763004
522 Joint Gear 9362772006 9362772006 9362772006 9362772006 9362772006 9362772006
540 By-pass Pipe-B 9363152005 9363152005 9363152005 9363152005 9363152005 9363152005
541 Terminal Plate 9363642001 9363642001 9363642001 9363642001 9363642001 9363642001
542 Panel Base 9362759014 9362759014 9362759014 9362759014 9362759014 9362759014
543 Panel Frame Holder 9362761017 9362761017 9362761017 9362761017 9362761017 9362761017
544 Panel Base Holder 9362760010 9362760010 9362760010 9362760010 9362760010 9362760010
545 Panel Frame 9362758017 9362758017 9362758017 9362758017 9362758017 9362758017
563 Insulation (Inner Box) 9362768009 9362768009 9362768009 9362768009 9362768009 9362768009
564 By-pass Pipe-A Assy 9363151008 9363151008 9363151008 9363151008 9363151008 9363151008
565 Evaporator Holder Assy 9362802017 9362802017 9362802017 9362802017 9362802017 9362802017
568 Noise Insulation 9363143003 9363143003 9363143003 9363143003 9363143003 9363143003
628 Locking Spacer-B 313005446558 313005446558 313005446558 313005446558 313005446558 313005446558
652-1 Thermistor Holder Pipe 313806262805 313806262805 313806262805 313806262805 313806262805 313806262805
690 Joint-A 9362773003 9362773003 9362773003 9362773003 9362773003 9362773003
692 Joint Shaft 9362771009 9362771009 9362771009 9362771009 9362771009 9362771009
705 Louver 9362769013 9362769013 9362769013 9362769013 9362769013 9362769013
710 Intake Grille 9362767019 9362767019 9362767019 9362767019 9362767019 9362767019
735 Distributor Assy 9363154009 9364795003 9363154009 9364795003 9363154009 9364795003
777-1 Grille Hook-A 9362779012 9362779012 9362779012 9362779012 9362779012 9362779012
777-2 Grille Hook-B 9362778015 9362778015 9362778015 9362778015 9362778015 9362778015
798 Pump Hook Bracket 9362753005 9362753005 9362753005 9362753005 9362753005 9362753005
803 Cabinet-D 9362734004 9362734004 9362734004 9362734004 9362734004 9362734004
814 Cabinet-C 9362733007 9362733007 9362733007 9362733007 9362733007 9362733007
815-1 Terminal 3P 9306489069 9306489069 9306489069 9306489069 9306489069 9306489069
815-2 Terminal 3P 9703345012 9703345012 9703345012 9703345012 9703345012 9703345012
834-1 Wire Cover-A 9362789004 9362789004 9362789004 9362789004 9362789004 9362789004
834-2 Wire Cover-B 9362788007 9362788007 9362788007 9362788007 9362788007 9362788007
835 Cushion Rubber (Pump) 9362777001 9362777001 9362777001 9362777001 9362777001 9362777001
847 Louver Supporter 9362770019 9362770019 9362770019 9362770019 9362770019 9362770019
858 Grille Spring 9362755009 9362755009 9362755009 9362755009 9362755009 9362755009
875 Filter PCB Assy -------- 9704561091 -------- 9704561091 -------- 9704561091
875 Filter PCB Assy 9704561107 -------- 9704561107 -------- 9704561107 --------
876-2 Step Motor 9360307019 9360307019 9360307019 9360307019 9360307019 9360307019
897 Coupling Pipe-A Assy 9363153002 9363153002 9363153002 9363153002 9363153002 9363153002
898 Coupling Pipe-B Assy 9363155006 9364806006 9363155006 9364806006 9363155006 9364806006
982-1 Cord Clamp 9356857009 9356857009 9356857009 9356857009 9356857009 9356857009
Ref.
No.
Description
Ord.
Q'ty
Part No.
AUG54ALB3W
AUG54ALB3W
AUG54RLB3W
AUY54ALB3W
AUY54RLB3W
AUT54ALB3W
AUT54RLB3W
