Fujitsu AOY54APA3L User Manual

2003.06.11
34 Capacitor (Fan Motor) 9703306068 9703306068
47-1 Rubber (Discha. Pipe) 313194159807 313194159807
61 Decoration Plate "GENERAL" 9365276013 9365652008
67 Rubber (Vibration Proof) 9362783002 9362783002
71 Grille Hook Holder 9362782005 9362782005
93 Filter 9362766005 9362766005
117-3 Hex. Nut w / Spring Washer 301721180114 301721180114
122 Louver Support Holder 9362799003 9362799003
127 Drain Hose 9362784009 9362784009
138 Separate Wall 9362737005 9362737005
143-3 Clamp NK-6N 9305657001 9305657001
146-1 Evaporator-A Assy 9363149005 9363149005
146-2 Evaporator-B Assy 9363150001 9363150001
155 Special Nut M6 9307615016 9307615016
160 Drain Pan Assy 9362804004 9362804004
164 Fan Motor Assy-IN 9600878019 9600878019
168 Cabinet-E 9362735001 9362735001
184-1 Thermo. Spring-A 313728262708 313728262708
187 Clamp No. 1219 313361271706 313361271706
195 Clamp SKB-100 313361275805 313361275805
196-2 Clamp SKB-150 313035356905 313035356905
197 Wind Guide Board 9363117004 9363117004
223 Control Box 9362762007 9362762007
226 Motor Gear 9362764001 9362764001
234 Thermistor Assy-Room 9703299025 9703299025
235 Thermistor Assy-Pipe 9703297014 9703297014
236 Controller PCB Assy 9704557308 9704557308
240 Remote Control Unit 9359913047 9359913047
244 Pipe Cover 9362748001 9362748001
337-1 Reinforcement (Eva.)-A 9362749008 9362749008
337-2 Reinforcement (Eva.)-B 9362750004 9362750004
338 Motor Holder 9362765008 9362765008
381 Locking Spacer 313209391506 313209391506
385 Indicator PCB Assy 9704017017 9704017017
457 Reinforcement (Drain Pan) 9362757003 9362757003
460-1 Pump Cover-A 9362775007 9362775007
460-2 Pump Cover-B 9362776004 9362776004
462 Top Cover Plate 9362806015 9362806015
464 Cabinet-A 9362800013 9362800013
465 Cabinet-B 9362801010 9362801010
467 Drain Port 9362786003 9362786003
468 Special Nut-A (Large) 313005446653 313005446653
469 Special Nut-B (Small) 313005446759 313005446759
472-1 Grille Reinforcement-A 9362738002 9362738002
472-2 Grille Reinforcement-B 9362739009 9362739009
472-3 Grille Reinforcement-C 9362740005 9362740005
472-4 Grille Reinforcement-D 9362741002 9362741002
472-5 Grille Reinforcement-E 9362742009 9362742009
474 Turbo Fan Assy 9362803014 9362803014
476-2 Special Washer 9362756006 9362756006
477 Bellmouth (B) 9362774000 9362774000
479 Float Switch 9703285004 9703285004
481 Insulation (Grille)-A 9362780001 9362780001
481-1 Insulation (Grille)-B 9362781008 9362781008
482 Pump Unit 9703125010 9703125010
484 Hook 9362736008 9362736008
487 Grille Hinge Wire 9362754002 9362754002
488 Drain Pan Plug 313005174654 313005174654
514 Control Box Cover 9362763004 9362763004
522 Joint Gear 9362772006 9362772006
540 By-pass Pipe-B 9363152005 9363152005
541 Terminal Plate 9363642001 9363642001
542 Panel Base 9362759014 9362759014
543 Panel Frame Holder 9362761017 9362761017
544 Panel Base Holder 9362760010 9362760010
545 Panel Frame 9362758017 9362758017
563 Insulation (Inner Box) 9362768009 9362768009
564 By-pass Pipe-A Assy 9363151008 9363151008
565 Evaporator Holder Assy 9362802017 9362802017
568 Noise Insulation 9363143003 9363143003
628 Locking Spacer-B 313005446558 313005446558
652-1 Thermistor Holder Pipe 313806262805 313806262805
690 Joint-A 9362773003 9362773003
692 Joint Shaft 9362771009 9362771009
705 Louver 9362769013 9362769013
710 Intake Grille 9362767019 9362767019
735 Distributor Assy 9363154009 9363154009
743 Remote Control Unit Holder Case 9359955016 9359955016
777-1 Grille Hook-A 9362779012 9362779012
777-2 Grille Hook-B 9362778015 9362778015
798 Pump Hook Bracket 9362753005 9362753005
803 Cabinet-D 9362734004 9362734004
814 Cabinet-C 9362733007 9362733007
815-1 Terminal 3P 9306489069 9306489069
834-1 Wire Cover-A 9362789004 9362789004
834-2 Wire Cover-B 9362788007 9362788007
835 Cushion Rubber (Pump) 9362777001 9362777001
847 Louver Supporter 9362770019 9362770019
858 Grille Spring 9362755009 9362755009
868 Holder (PCB) 9364855004 9364855004
875 Filter PCB Assy 9704561107 9704561107
876-2 Step Motor 9360307019 9360307019
897 Coupling Pipe-A Assy 9363153002 9363153002
898 Coupling Pipe-B Assy 9363155006 9363155006
982-1 Cord Clamp 9356857009 9356857009
When you order parts, please make a photocopy of this page
and fill the number of the parts in the "Order" column.
INDOOR UNIT
Ref.
No.
Description
Ord.
Q'ty
Part No.
Ref.
No.
Description
Ord.
Q'ty
Part No.
AUY54AGB3WAUG54AGB3W AUY54AGB3WAUG54AGB3W
AUG54AGB3W
AUY54AGB3W
- 23 -
