INDOOR UNIT
PARTS
2009.07.13 20
8
4
4
7
3
6
5
1
2
5 Hanger Bracket L 9358596005
6 Hanger Bracket R 9358595008
7 Cosmetic Panel R 9358535011
8 Cosmetic Panel L 9358536018
1 Remote Control 9315885012
2
Remote Control Holder
9305642045
3 Top Cover 9358534014
4 Arm 9358565001
9358596005
9358595008
9358535028
9358536025
9315885012
9305642045
9358534021
9358565001
Ref. Description
Part number
LAT LBT
