2009.07.13 27
81
82
83
84
ABYF24L_T
82
83
84
81
81 Evaporator Assy 9362513043 9362513050
82 Bypass Pipe Assy 9377819017 9377821010
83
84
Distributor Assy 9371325354 9371325361
Coupling Pipe Assy 93730383999373038382
ABYF24L_T
Ref. Description
Part number
ABYF18L_T
INDOOR UNIT
ABYF18L_T
Evaporator
