Page #25 background imageLoading...
Page #25 background image
14
15
12
13
11
OUTDOOR UNIT
2008.01.18 24
15 Propeller Fan Assy 9366378020
14 Fan Motor 9602717019
12 Condenser A Assy 9374433056
13 Separate Wall 9374413188
11 Base Assy 9374166138
Ref. Part numberDescription
www.enindel.com
