PARTS
INDOOR UNIT
Intake grille sub assy
2007.02.27 17
12
15
13
7
9
9
9
16
16
11
8
9
10
12
15
10
3
2
1
10
6
14
4
5
1 Decoration Plate
12
Grille Hook Holder
4
Filter
5
Grille Reinforcement-T (A)
16 Grille Hinge Wire 9362754002
2
Intake Grille Sub Assy
9362818131
3
Intake Grille
9362767019
13
Grille Hook-A 9362779012
14
Grille Hook-B 9362778015
15
Grille Spring 9362755009
10
Insulation (Grille)-A
9362780001
11
Insulation (Grille)-B 9362781008
9378017016
9362782005
9362766005
9362738002
7
Grille Reinforcement-T (C)
8
Grille Reinforcement-T (D)
9
Grille Reinforcement-T (E)
9362740005
9362741002
9362742009
Description
Parts number
Ord.
Q'ty
Ref.
No.
6
Grille Reinforcement-T (B)
9362739009
