Page #20 background imageLoading...
Page #20 background image
63
58
62
57
56
59
62
60
61
52
49
50
42
41
54
53
51
51
55
54
54
50
INDOOR UNIT
Evaporator
Drain pan
2007.04.02 19
45
46
47
42
41
48
43
44
57 Drain Hose
45 Separate Wall
41 Evaporator A Assy
42 Evaporator B Assy
53 Kit (Drain Pan Assy)
48 Thermistor Spring-A
46 Clamp No.1219
47 Pipe Thermistor
54 Reinforcement (Drain Pan)
60 Pump Cover-A
61 Pump Cover-B
58 Drain Port
63 Float Switch 9900361020
56 Pump Unit 9900360030
49 Evaporator Holder Assy
9362802017
43 Distributor Assy 9371325101
59 Drain pump Holder 9362753005
62 Cushion Rubber (Pump) 9362777001
44 Coupling Pipe Assy 9373038290
--- Rubber (Discharge Pipe) 313194159807
55 Rubber Cap
313005174654
Description
Parts number
Ord.
Q'ty
Ref.
No.
9362784009
9362737005
9373799047
9373800040
9370934021
313728262708
313361271706
50 Wind Guide Board 9373444015
9703297021
51 Reinforcement (Eva. )-A
52 Reinforcement (Eva. )-B
9362749008
9362750004
9362757003
9362775007
9362776004
9362786003
