W606
W605
VA604
470V
<TNR>
VA603
470V
<TNR>
SA601
RA-362M
W607
E
GREEN
BLUE
W602
VA601
470V
<TNR>
N I N
L3 I N
W603
FH603
F602
SHV14
15A - 400V
BLACK
L601
SC-10-55JH
C601
1.0
<ECQU>
C603
0.22
<ECQU>
C604
0.010
<ECQU>
C605
0.010
<ECQU>
N OUT
L3 OUT
BLACK
BLUE
FH604
2
1
4
3
H-0017-2 x 2
POWER SOURCE
FILTER PCB ( MAIN )
K07CH-0900HUE-FL0
2013.01.30
15
OUTDOOR UNIT
