Fujitsu AOYA90LALT - Dimensions

Drain pipe diameter
Inside : 36.0 mm
Outside : 38.0 mm
INDOOR UNIT
ARYC72LHTA
(unit : mm)
DIMENSIONS
22010.03.29
700
29
42
227
311
404
427
38
653 (BOLT PITCH)
50 25
50 25
65
15
450
370
15
35350
P160x2 =320
3
1250 149
81
60
49
1587
1410 (BOLT PITCH)
75
125
1171450
1200
P150 X 7 =1050
MAIN DRAIN PORT
SAFETY DRAIN PORT
FRONT VIEW
SIDE VIEW (R)
REAR VIEW
SIDE VIEW (L)
AIR FLOW
TOP VIEW
