2013.02.28 18
32 Compressor Assy 9317083034
26 3-way Valve Assy 9317174015
28 2-way Valve Assy 9317171014
33 Solenoid 9970079030
31 Condenser Total Assy 9332924008
25 Muffler 9317394000
35 Expansion Valve Coil 9970137013
34 4-way Valve Assy 9333012001
36
Pulse Motor Valve Sub Assy
9333023007
Ref. Description Part number
OUTDOOR UNIT
AOYG07LMCA
AOYG09LMCA
33
32
31
36
34
35
