OUTDOOR UNIT
AOYG12LMCA
42
41
43
46
45
44
2013.02.28 19
42 Compressor Assy 9332603002
36 3-way Valve Assy 9317174015
46
Pulse Motor Valve Sub Assy
9333023007
45 Expansion Valve Coil 9970137013
43 Solenoid 9970079030
41 Condenser Total Assy 9333013008
35 Muffler 9317398008
44 4-way Valve Assy 9333015002
38 2-way Valve Assy 9317171014
Ref. Description Part number
