35
34
36
37
32
33
15
31
Evaporator Total Assy (12)
9319327006
31
Evaporator Total Assy (14)
9319327013
32 Joint Pipe Assy (14) 9319322018
32 Joint Pipe Assy (12) 9319322001
33 Joint Pipe Holder 9318901009
35
34
Filter Guide 9318887006
36 Evaporator Holder L 9318875003
Base 9318874006
37 Air Seal 9319295008
Ref. Description Part number
INDOOR UNIT
Evaporator
2011.03.11
31
