43
49
48
44
42
41
46
47
45
INDOOR UNIT
Control box
16
46
Terminal 9900638009
Main PCB (ASYG12LUCA)
9708713304
45
Earth Terminal 9318918007
41
Control Box
9318916003
42
Cover Shield A
9318882001
43 Box Shield Assy 9319344003
44
Main PCB (ASYG14LUCA)
970871331144
49 Step Motor 9900384166
47
Room Thermistor Holder
9319068008
48 Gear Cover 9318902006
Ref. Description Part number
56
Indicator PCB 970882401757
-- Thermistor Assy 9900627003
Display Assy 9708823010
54 Grille Key Top 9319334004
55 Micro Switch 9900625009
51 Panel Gear 9319293004
Switch Case 9319332000
52
53
Gear Case 9318903003
50 Gear B 9319294001
Ref. Description Part number
2013.03.04
52
53
50
51
54
55
56
57
To Next Page
