Fujitsu AOYG14LALL User Manual

INDOOR UNIT
A C C E S S O R I E S
212011.12.12
DECORATION PANEL
Name and Shape Q’ty Application
Connector cover
1
For covering connector
Tapping Screw
(M5 × 12 mm)
4
For mounting decora-
tion panel
Tapping Screw
(M4 × 12 mm)
1
For mounting connec-
tor cover
L angle
2
For mounting the Hook
Wire to the Decoration
panel
Hook wire
2
For suspending the
Decoration panel
Screw [pitch small]
(M4 × 10 mm)
2
For mounting the Hook
Wire (for metals)
Screw [pitch large]
(M4 × 10 mm)
4
For mounting the
L angle and Hook wire
(for resins)
Name and Shape Q’ty Application
Special nut A
(Large flange)
4
For installing indoor unit
Special nut B
(Small flange)
4
For installing indoor unit
Template
(Carton top)
1
For cealing openings cutting
Also used as packing
Drain hose
1
For installing drain pipe
Hose Band
1
For installing drain hose
Drain hose insulation
1
For installing drain pipe
Remote control
1
For air conditioner operation
Battery
2
For remote control
Remote control
holder
1
For installing the remote
control
Tapping screw
(M3 × 12mm)
2
For mounting the remote
control holder
Binder
2
For electrical wiring
Wire clamper
1
For electrical wiring
Coupler heat
insulation
(Small)
1
For indoor side pipe
joint (Liquid pipe)
Coupler heat
insulation
(Large)
1
For indoor side pipe
joint (Gas pipe)
1
1
For drain piping work.
9303029015
Drain pipe
To connect
12,000 BTU model
9370244007
Adapter assy
Q'ty
