Page #31 background imageLoading...
Page #31 background image
R201 220 <1/4W>
R202 390 <1/4W>
R203 220 <1/4W>
D203 SLR-3
2
D201 SLR-3
2
D202 SLR-3
2
P I
SW201
EVQPAG04K
C202
10/
25V
+
C201
0.1
<F>
2
43
1
CN201
S07B-PASK-2
1
2
3
4
5
6
7
TO MAIN PCB
INDOOR UNIT
INDICATOR PCB
K06AG-1000HSE-D0
2013.01.24 8
