INDOOR UNIT
ASYG14LMCE
2016.11.07 11
11
12
14 Front Panel Sub
Assy (FUJITSU)
9333525051
Wire Cover 9333504018
Wire
Shield
Ref. Description Part number
Louver Assy 9333353043
13 Diffuser Assy 9332998085
14
11
12
13
