Name and Shape Part number
0600185541
9310519004
Battery (penlight)
Cloth tape
ACCESSORIES
2016.11.21 21
INDOOR UNIT
Remote Control
9319208008
Remote Control Holder 9318912005
Bracket Panel
9332882025
Name and Shape Part number
9332911008
0700076046
9317250009
Filter holder
Air cleaning filter assy
Tapping screw
(M4 x 25 mm)
Tapping screw
(M3 x 12 mm)
0700019036
Name and Shape
9303029022
OUTDOOR UNIT
Drain pipe assy
