57
55
53
56
51
52
54
INDOOR UNIT
ASYG14LMCE
Casing assy
15
Fan Guard 9332905007
56
57
54
Drain Hose Assy 9316904002
Drain Cap 9316177017
51
Casing Cover B 9332908008
Casing Cover F 9332909005
R and L Louver 9332891003
Casing 9332890006
55
52
53
Ref. Description Part number
2016.11.07
