14
OUTDOOR UNIT
AOYG14LMCE
2016.11.24
Motor
bracket
assy
Shield panel
18
14 Terminal 9900435028
13 Reactor Assy 9900788018
11 Propeller Fan 9313808013
12 Fan Motor 9602864041
Ref. Description Part number
11
12
13
