13. Function settings
Perform appropriate function setting locally according to the installation environment.
NOTE:
Incorrect settings can cause a product malfunction.
CAUTION
• Before setting up the switch buttons, discharge the static electricity from your body.
• Never touch the terminals or the patterns on the parts that are mounted on the PCB.
13-1. Control PCB and switch buttons location
Control PCB of the outdoor unit is located as shown in the following figure.
- 102 -
13-1. Control PCB and switch buttons location 13. Function settings
OUTDOOR UNIT
AOYG18-45KBTB
OUTDOOR UNIT
AOYG18-45KBTB
To Next Page
