1. Specifications
Type
Wall mounted
Inverter heat pump
Model name ASYG18KMTE ASYG24KMTE
Power supply 230 V ~ 50 Hz
Power supply intake Outdoor unit
Available voltage range 198—264 V
Capacity
Cooling
Rated
kW 5.20 7.10
Btu/h 17,700 24,200
Min.—Max.
kW 0.90—6.00 0.90—8.30
Btu/h 3,100—20,500 3,100—28,300
Heating
Rated
kW 6.30 8.00
Btu/h 21,500 27,200
Min.—Max.
kW 0.90—8.70 0.90—10.10
Btu/h 3,100—29,600 3,000—34,400
Input power
Cooling
Rated
kW
1.39 2.08
Min.—Max. 0.09—1.66 0.24—3.15
Heating
Rated 1.56 1.91
Min.—Max. 0.09—2.86 0.14—3.00
Fan
HIGH
W
37.5 61.6
MED 22.9 26.7
LOW 13.3 13.3
QUIET 8.2 8.2
Current
Cooling
Rated A
6.1 9.3
Heating 7.0 8.6
EER Cooling
kW/kW
3.74 3.41
COP Heating 4.04 4.19
Sensible capacity Cooling kW 4.05 5.30
Power factor
Cooling
%
98 98
Heating 98 96
Moisture removal L/h (pints/h) 1.7 (3.0) 2.7 (4.8)
Maximum operating current *1
Cooling
A
9.5 13.5
Heating 13.5 16.0
Fan
Airflow rate
Cooling
HIGH
m
3
/h
980 1,170
MED 810 850
LOW 640 640
QUIET 510 510
Heating
HIGH 1,020 1,170
MED 850 850
LOW 640 640
QUIET 510 510
Type × Q'ty Crossflow fan × 1
Motor output W 59
Sound pressure level *2
Cooling
HIGH
dB (A)
45 49
MED 40 40
LOW 35 35
QUIET 29 29
Heating
HIGH 46 49
MED 40 40
LOW 35 35
QUIET 29 29
Heat exchanger type
Dimensions (H × W × D)
mm
Main1: 210 × 798 × 26.6, Main2: 135 × 798 × 20
Sub1: 84 × 798 × 13.3, Sub2: 84 × 798 × 13.3
Fin pitch
Main1: 1.2, Main2: 1.1
Sub1: 1.4, Sub2: 1.4
Rows × Stages
Main1: 2 × 10, Main2: 2 × 8
Sub1: 1 × 4, Sub2: 1 × 4
Pipe type Copper
Fin type Aluminum
Enclosure
Material Polystyrene
Color
White
Approximate color of Munsell N 9.25/
Dimensions
(H × W × D)
Net
mm
280 × 980 × 240
Gross 322 × 1,078 × 346
Weight
Net
kg
12.5
Gross 18
Connection pipe
Size
Liquid
mm (in)
Ø6.35 (Ø1/4)
Gas Ø12.70 (Ø1/2)
Method Flare
Drain hose
Material PP + HDPE
Tip diameter mm Ø13.8 (I.D.), Ø15.8 to Ø16.7 (O.D.)
Operation range
Cooling
°C 18 to 32
%RH 80 or less
Heating °C 16 to 30
Remote control
Wireless remote controller (Option: Wired remote controller, Mobile app*3 [FGLair
™
])
NOTES:
• Specifications are based on the following conditions:
– Cooling: Indoor temperature of 27 °CDB/19 °CWB, and outdoor temperature of 35 °CDB/24 °CWB.
– Heating: Indoor temperature of 20 °CDB/15 °CWB, and outdoor temperature of 7 °CDB/6 °CWB.
– Pipe length: 5 m, Height difference: 0 m. (Between outdoor unit and indoor unit.)
• Protective function might work when using it outside the operation range.
• *1: Maximum operating current is the total current of the indoor unit and the outdoor unit.
• *2: Sound pressure level:
– Measured values in manufacturer’s anechoic chamber.
– Because of the surrounding sound environment, the sound levels measured in actual installation conditions might be higher than the specified values here.
• *3: Available on Google Play
™
store or on App Store
®
. Optional WLAN adapter is also required. For details, refer to the setting manual.
- 2 -
1. Specifications
WALL MOUNTED ASYG18-24KMTE WALL MOUNTED ASYG18-24KMTE

Fujitsu AOYG18KMTA Specifications

General
