Fujitsu AOYG18LBCA Service Manual

5 Main PCB (AUXG18LRLB)
Box shield
INDOOR UNIT
AUXG18LRLB
AUXG24LRLB
2015.11.24 15
9710016165
5
Main PCB (AUXG24LRLB) 9710016172
1 Cable Guide
2 Room Thermistor Holder
9381376001
9381348008
2
Ref. Description Part number
6
7
5
11
10
1
8
9
3 Room Thermistor
4 Pipe Thermistor
9900822002
9900903008
6 Power PCB
7 PCB (Non-polar 2-wire)
9710022005
10 Main PCB Holder 9381350001
11 Power PCB Holder 9381349005
9710019005
8 Remote Terminal 5P
9 Power Terminal 3P
9900896003
9900720032
3
4
