Page #17 background imageLoading...
Page #17 background image
21 Bellmouth
22 Turbo Fan Assy
24 Nut
25 Brushless Motor
2015.11.25
INDOOR UNIT
AUXG18LRLB
AUXG24LRLB
9381484003
9381303007
9356998009
23 Turbo Fan Washer 9378394018
28 Drain Pan Sub Assy 9381789009
9603443009
27 Motor Wire Holder
26 Special Nut
9381351008
9378388017
Ref. Description
Part number
24
21
25
22
26
23
16
27
28
