4-2. Heating capacity
NOTE: Values mentioned in the table are calculated based on the maximum capacity.
¢
Model: ABYG18KRTA
AFR
m
3
/h
840
Indoor temperature
°CDB 16 18 20 22 24
Outdoor temperature
°CDB °CWB
TC IP TC IP TC IP TC IP TC IP
kW kW kW kW kW
-15 -16 4.24 1.38 4.14 1.40 4.04 1.43 3.94 1.46 3.84 1.49
-10 -11 4.78 1.46 4.67 1.49 4.55 1.52 4.44 1.55 4.33 1.58
-5 -7 5.32 1.55 5.19 1.58 5.07 1.61 4.94 1.65 4.81 1.68
0 -2 5.86 1.65 5.72 1.68 5.58 1.71 5.44 1.75 5.30 1.78
5 3 6.39 1.73 6.24 1.76 6.09 1.80 5.94 1.83 5.79 1.87
7 6 6.62 1.76 6.46 1.79 6.30 1.83 6.14 1.87 5.99 1.90
10 8 7.14 1.83 6.97 1.87 6.80 1.90 6.63 1.94 6.46 1.98
15 10 7.11 1.61 6.94 1.65 6.77 1.68 6.60 1.71 6.43 1.74
20 15 6.69 1.27 6.53 1.30 6.37 1.32 6.21 1.35 6.05 1.37
24 17 7.06 1.26 6.89 1.29 6.72 1.32 6.55 1.34 6.38 1.36
¢
Model: ABYG22KRTA
AFR
m
3
/h
900
Indoor temperature
°CDB 16 18 20 22 24
Outdoor temperature
°CDB °CWB
TC IP TC IP TC IP TC IP TC IP
kW kW kW kW kW
-15 -16 5.18 1.87 5.05 1.91 4.93 1.95 4.81 1.98 4.68 2.02
-10 -11 5.68 1.94 5.55 1.99 5.41 2.03 5.28 2.07 5.14 2.11
-5 -7 6.20 2.01 6.05 2.05 5.90 2.10 5.75 2.14 5.61 2.18
0 -2 6.71 2.07 6.55 2.12 6.39 2.16 6.23 2.20 6.07 2.25
5 3 7.23 2.14 7.05 2.19 6.88 2.23 6.71 2.27 6.54 2.32
7 6 7.77 2.14 7.59 2.19 7.40 2.23 7.22 2.27 7.03 2.32
10 8 7.45 2.02 7.27 2.06 7.09 2.11 6.92 2.15 6.74 2.19
15 10 6.93 1.83 6.76 1.86 6.60 1.90 6.43 1.94 6.27 1.97
20 15 6.51 1.55 6.35 1.58 6.20 1.62 6.04 1.65 5.89 1.67
24 17 6.77 1.54 6.61 1.57 6.45 1.60 6.29 1.63 6.12 1.66
¢
Model: ABYG24KRTA
AFR
m
3
/h
1,230
Indoor temperature
°CDB 16 18 20 22 24
Outdoor temperature
°CDB °CWB
TC IP TC IP TC IP TC IP TC IP
kW kW kW kW kW
-15 -16 6.02 2.12 5.87 2.16 5.73 2.21 5.59 2.25 5.44 2.30
-10 -11 6.60 2.21 6.45 2.25 6.29 2.30 6.13 2.34 5.97 2.39
-5 -7 7.20 2.28 7.03 2.33 6.86 2.38 6.69 2.43 6.52 2.47
0 -2 7.80 2.35 7.61 2.40 7.43 2.45 7.24 2.50 7.06 2.55
5 3 8.40 2.43 8.20 2.48 8.00 2.53 7.80 2.58 7.60 2.63
7 6 9.03 2.43 8.82 2.48 8.60 2.53 8.39 2.58 8.17 2.63
10 8 8.66 2.29 8.45 2.34 8.25 2.39 8.04 2.44 7.83 2.48
15 10 8.05 2.07 7.86 2.11 7.66 2.16 7.47 2.20 7.28 2.23
20 15 7.56 1.76 7.38 1.80 7.20 1.83 7.02 1.87 6.84 1.90
24 17 7.87 1.74 7.68 1.78 7.49 1.81 7.31 1.85 7.12 1.88
- 16 -
4-2. Heating capacity 4. Capacity table
CEILING TYPE ABYG18-45KRTA CEILING TYPE ABYG18-45KRTA
