Item no. Part no. Part name Service part
1 9322556073 Top panel assy ♦
2 9322811042 Protective net ♦
3 9322552266 Cabinet right assy ♦
4 9322554031 Terminal cover assy ♦
5 9322570079 Switch cover assy ♦
6 9322267016 Shield panel ♦
7 9900369088 Terminal (Power) ♦
8 9900369071 Terminal (Inner) ♦
9 9711609007 Indicator PCB ♦
10
9711432315 Main PCB (For 18 model) ♦
9711432322 Main PCB (For 24 model) ♦
11 9900565008 Thermistor assy (Outdoor temp.) ♦
12 9900727048 Thermistor assy ♦
13 9900985035 Compressor thermistor ♦
14 9709685778 Inverter PCB ♦
15 9322379009 IPM spacer R ♦
16 9322250001 IPM spacer L ♦
17 9322421043 Heat sink ♦
18 9322144003 Drain pipe ♦
19 9322322050 Base assy ♦
20 9319151007 Emblem ♦
21 9322149008 Blow grille ♦
22 9322555373 Front panel assy ♦
23 9322150004 Propeller fan ♦
24 9603601003 DC fan motor ♦
25 9322553034 Motor bracket assy ♦
26 9900984045 Thermistor (Heat exchanger) ♦
27 9323834644 Heat exchanger unit ♦
a — Hair pin cushion —
4-1. Models: AOYG18KBTA3 and AOYG24KBTA3 - (02-93) - 4. Outdoor unit parts list
