¢ Models: ARXG07–18KSLAP, ARXG07–18KLLAP, ASYG12–
14KGTB, ASYG12–14KGTE, ASYG12–14KGTF, ASYG18KMTB,
ASYG18KMTE, ASYG07–14KMCE, ASYG07–14KMCF,
ASYG14KETA, ASYG14KETA-B, ASYG14KETE, ASYG14KETE-
B, ASYG14KETF, ASYG14KETF-B, and ABYG18KRTA
Check point 1. Check rotation of fan
Rotate the fan by hand when operation is off.
(Check if fan is caught, dropped off or locked motor)
→ If fan or bearing is abnormal, replace it.
Check point 2. Check resistance of indoor fan motor
Refer to below. Circuit-test “Vm” and “GND” terminal
NOTE: Vm: DC voltage, GND: Earth terminal
→ If they are short-circuited (below 300 kΩ), replace indoor fan motor and controller PCB.
Pin number
(wire color)
Terminal function
(symbol)
1 (Red) DC voltage (Vm)
2 No function
3 No function
4 (Black) Ground terminal (GND)
5 (White) Control voltage (Vcc)
6 (Yellow) Speed command (Vsp)
7 (Blue) Feed back (FG)
5-4. Indoor unit fan motor - (03-95) - 5. Service parts information
