- 69 -
DUCT TYPE ARYG12-54LHTBP
11-2. Function settings by using remote controller
Some function settings can be changed on the remote controller. After confirming the setting proce-
dure and the content of each function setting, select appropriate functions for your installation envi-
ronment.
NOTE: Incorrect settings can cause a product malfunction.
 Setting procedure by using wired remote controller
The function number and the associated setting value are displayed on the LCD of the remote
controller. Follow the instructions written in the local setup procedure supplied with the remote
controller, and select appropriate setting according to the installation environment.
Before turning on the power of the indoor unit, reconfirm following items:
• Piping air tight test and vacuuming have been performed firmly.
• There is no wiring mistake.
1. Turn on the power.
2. Touch the “Function Setting” on the “Maintenance” screen. The “Function Setting” screen is
displayed. Then touch the “Address” on the “Function Setting” screen.
3. “Address” screen is displayed. Select the address of the indoor unit whose function number is
to be set by touching ▲ or ▼. When setting at all the indoor units, touch “All”.
NOTE: Perform this step only when the remote controller address setting is required. Otherwise,
skip this step.
4. Touch the “Function No.” on the “Function Setting” screen.
5. “Function No.” screen is displayed. Set the function number “11” by touching ▲ or ▼. When
the “OK” is touched, the display returns to the “Function Setting” screen.
[002–01]
[00]
[00]
Address
Function No.
Setting No.
Function Setting
Back Setting
002–01
Address
Cancel OK
All
[002–01]
[00]
[00]
Address
Function No.
Setting No.
Function Setting
Back Setting
11
Function No.
Cancel OK
