REFRIGERANT SYSTEM DIAGRAM
2-Way
valve
Strainer
Strainer
3-Way
valve
Muffler
Muffler
4-Way valve
Expansion valve
Heat exchanger
( INDOOR )
Heat exchanger
( OUTDOOR )
AOYS09LDC
(2Pass)
AOYR12LCC
AOYS12LDC
(4Pass)
Compressor
Cooling
Heating
ASYB09LDC / AOYS09LDC
ASYB12LDC / AOYS12LDC
Models : ASYA12LCC / AOYR12LCC
03-02
