OUTDOOR UNIT
1 Top Panel Assy 9309230057
2 Top Panel Seal 9309228016
3 Cabinet Assy 9314809040
4 Blow Down Grille 9308884015
5 Cabinet Right Assy 9309236011
6 Fan Ring 9308885012
7 Grip 9308880017
8 Switch Cover 9308882028
9 Protective Net 9315319012
10 4-Way Valve Assy 9315726018
11 Expansion Valve Assy 9311641018
13 Condenser 9311381037
14 Thermistor Spring-A 313728262708
15 Thermistor Spring 9300089012
16 Propeller Fan 9309909014
17 Nut 9304902003
18 Motor Bracket 9308872012
19 Separator Assy 9312971015
20 Base Assy, Painted 9308869081
21 3-Way Valve Assy 9315159014
22 2-Way Valve Assy 9313064013
24 Cord Clamp 9307271014
25 Terminal 9306489038
26 Inverter PCB Assy 9707039153
29 Fuse 0600382018
32 Expansion Valve Coil 9900057039
34 Fan Motor 9601725015
35 Compressor Assy 9313764012
36 Emblem 9315210012
Outdoor Thermistor
39 Solenoid Coil 9970033018
-- IPM 9705720015
-- 9900210045
Thermistor Assy-- 9900148027
Ref. Description Part number
2006.06.13 16
