Fujitsu ARG45ALC3 User Manual

- 1 -
2004.01.21
REFRIGERANT CHARGE (R-22)
PIPE LENGTH 5 m 10 m 20 m 30 m 40 m 50 m
MODELS (16 ft) (33 ft) (66 ft) (99 ft) (132 ft) (164 ft)
ARG45ALC3 3,150 g 3,550 g 3,950 g 4,350 g
FULL CHARGE ARY45ALC3 (111.1 oz) (125.2 oz) (139.3 oz) (153.4 oz)
AMOUNT 3,400 g 3,800 g 4,200 g 4,600 g
(119.9 oz) (134.0 oz) (148.2 oz) (162.3 oz)
SPECIFICATIONS
INDOOR UNIT ARG45ALC3, ARY45ALC3 ARG45RLC3, ARY45RLC3, ART45RLC3
OUTDOOR UNIT AOG45APA3L, AOY45APA3L AOG45RPA3L, AOY45RPA3L, AOT45RPA3L
COOLING CAPACITY (kW) 12.4 - 12.7 12.4 - 12.7
HEATING CAPACITY (kW) ----- 13.4 - 13.7
POWER SOURCE (V) 380 - 415
FREQUENCY (Hz) 50
RUNNING CURRENT (A)
COOLING 8.10 - 8.30 8.10 - 8.30
HEATING ----- 7.80 - 8.10
INPUT WATTS (kW)
COOLING 4.50 - 4.57 4.50 - 4.57
HEATING ----- 4. 2 5 - 4 . 3 5
E.E.R. (kW/kW)
COOLING 2.76 - 2.78 2.76 - 2.78
HEATING ----- 3.15 - 3.15
MOISTURE REMOVAL ( /hr) 6.0 4.5
AIR CIRCULATION-Hi (m
3
/hr) 2,200 2,200
ELECTRICAL DATA
COMPRESSOR
DIMENSIONS
TYPE Hermetic type, 2 pole, Three phase, Induction motor
CODE ZR61KC-TFD-559
ARG45ALC3, ARG45RLC3 AOG45APA3L
ARY45ALC3, ARY45RLC3, ART45RLC3 AOY45APA3L
TYPE MFA-45BTT MFB-362FT
POWER SOURCE (V) 380 - 415
HI-SPEED (r.p.m.) 1,320 770 790
MED-SPEED (r.p.m.) 1,270 ----- -----
LO-SPEED (r.p.m.) 1,200 ----- -----
HEIGHT (mm) 270 1,152
WIDTH (mm) 1,210 940
DEPTH (mm) 700 370
FAN MOTOR
WEIGHT
GROSS WEIGHT (kg) 60 116 124
NET WEIGHT (kg) 45 102 110
Notes : • Between 5 m and 50 m, when using a connection pipe other than that in the table, charge additional refrigerant with 40 g (1.41oz) /
1 m (3.3 ft) as the criteria.
• The above list shows values at the external static pressure of 10 mm Aq (98 Pa).
ARG45RLC3
ARY45RLC3
ART45RLC3
AOG45RPA3L
AOY45RPA3L
AOT45RPA3L
