Fujitsu ARG45ALC3 User Manual

- 22 -
2004.01.21
AOG45APA3L
AOG45RPA3L
AOY45APA3L
AOY45RPA3L
AOT45RPA3L
AOY45APA3L
When you order parts, please make a photocopy of this page
and fill the number of the parts in the "Order" column.
OUTDOOR UNIT
2 Fan Cover 9352159015 9352159015 9352159015 9352159015 9365905012
4 Emblem-Rear 313791088308 313791088308 9351355005 9351355005 9351355005
5 Cabinet-A, Painted 9352146015 9352146015 9352146015 9352146015 9352146015
6 Cabinet-C, Painted 9352149016 9352149016 9352149016 9352149016 9352149016
9 Cabinet-B, Painted 9352147012 9352147012 9352147012 9352147012 9352147012
12 Base Assy, Painted 9352136016 9352136016 9352136016 9352136016 9352136016
15 Dryer 9368111014 9368111014 9368111014 9368111014 9368111014
16-1 Condenser-A Assy 9369544002 9355338011 9369544002 9355338011 9355338011
16-2 Condenser-B Assy 9369545009 9353363008 9369545009 9353363008 9353363008
18 Suction Pipe Assy 9372226018 9372226018 9372226018 9372226018 9372226018
20 Discharge Pipe Assy 9370950052 ---------- 9370950052 ---------- ----------
21 Discharge Pipe-B ---------- 9372246016 ---------- 9372246016 9372246016
26 Compressor Cover-A 9370774030 9370774030 9370774030 9370774030 9370774030
29 Separate Wall Assy 9355277013 9355277013 9355277013 9355277013 9355277013
30 Blower Cover, Painted 9352151019 9352151019 9352151019 9352151019 9352151019
32 Control Box Metal 9352134012 9352134012 9352134012 9352134012 9352134012
34 Capacitor (Fan Motor) 9357965024 ---------- 9357965024 ---------- ----------
36 Cord Holder Metal 9356934007 9356934007 9356934007 9356934007 9356934007
39 Propeller Fan Assy 9366378013 9366378013 9366378013 9366378013 9366378013
41 Fan Motor Assy-Out 9600832028 9600832028 9600832028 9600832028 9600832028
45 Bracket (Motor) Assy 9368108007 9368108007 9368108007 9368108007 9368108007
46 Compressor Assy 9371396026 9371396026 9371396026 9371396026 9371396026
48 Bracket (Coupler) Assy 9355281010 9355281010 9355281010 9355281010 9355281010
55 Special Nut M8 (For Comp.) 9355091008 9355091008 9355091008 9355091008 9355091008
64 Capacitor (Fan Motor) ---------- 9357965024 ---------- 9357965024 9357965024
107 Rubber Seat-A (For Comp.) 9364084008 9364084008 9364084008 9364084008 9364084008
108 Sleeve-A (For Comp.) 9364085005 9364085005 9364085005 9364085005 9364085005
109 Terminal Cover (For Comp.) 9364087009 9364087009 9364087009 9364087009 9364087009
111 Terminal Packing 9364086002 9364086002 9364086002 9364086002 9364086002
182 Clamp No. 249 ---------- 313361271505 ---------- 313361271505 313361271505
184-1 Thermo. Spring-A ---------- 313728262708 ---------- 313728262708 313728262708
185 Rubber Bushing 313005066051 313005066051 313005066051 313005066051 313005066051
236 Controller PCB Assy ---------- 9704764096 ---------- 9704764096 9704764096
272 Strainer Assy ---------- 9354139008 ---------- 9354139008 9354139008
300 Suction Pipe-C 9372227015 ---------- 9372227015 ---------- ----------
330 Inlet Pipe (Cond.)-A ---------- 9372239018 ---------- 9372239018 9372239018
333 Accumulator ---------- 9350363018 ---------- 9350363018 9350363018
333-2 Accumulator Assy (B) 9371615011 9371615011 9371615011 9371615011 9371615011
334 Suction Pipe-B ---------- 9372227015 ---------- 9372227015 9372227015
343 Solenoid Coil ---------- 9900165024 ---------- 9900165024 9900165024
344-2 4-Way Valve ---------- 9970035012 ---------- 9970035012 9970035012
354 Pressure Switch ---------- 9704045003 ---------- 9704045003 9704045003
373 Grip 9352157004 9352157004 9352157004 9352157004 9352157004
381 Locking Spacer ---------- 313209391506 ---------- 313209391506 313209391506
401 Terminal-2P 9701971015 ---------- 9701971015 ---------- ----------
405 Clamp No. 1763 313816345304 313816345304 313816345304 313816345304 313816345304
407 Clamp (Cable) No. 1259 313739340109 313739340109 313739340109 313739340109 313739340109
420 Capillary Assy 9371224084 ---------- 9371224084 ---------- ----------
450 Discharge Pipe-A 9370951097 9372229019 9370951097 9372229019 9372229019
527 Protection Net 9352163012 9352163012 9352163012 9352163012 9352163012
549 Thermostat-Outdoor 9352426001 ---------- 9352426001 ---------- ----------
575 Condensing Pipe-C 9372225011 9372225011 9372225011 9372225011 9372225011
620 Inlet Pipe (Cond.) Assy 9372224014 9372224014 9372224014 9372224014 9372224014
628 Locking Spacer ---------- 313005446558 ---------- 313005446558 313005446558
646 Compressor Cover-B 9370774047 9370774047 9370774047 9370774047 9370774047
653-1 Bolt (Fan Motor Fixing) 9385089020 9385089020 9385089020 9385089020 9385089020
678 Bracket (Thermistor) ---------- 313557406106 ---------- 313557406106 313557406106
734 Cabinet Top Plate 9352161018 9352161018 9352161018 9352161018 9352161018
735 Distributor Assy 9372230015 9372230015 9372230015 9372230015 9372230015
772 Joint Pipe (Valve-A) 9370739039 ---------- 9370739039 ---------- ----------
Ref.
No.
Description
AOG45APA3L AOG45RPA3L
Ord.
Q'ty
Part No.
AOY45RPA3L AOT45RPA3L
