Fujitsu ARHG45LHTA

2
PARTS
3
15
9
16
13
14
6
7
5
8
11
1
INDOOR UNIT
182012.04.12
(Connector : black)
12
13 Drain Pan Assy
12 Pipe Thermistor
8 Sirocco Fan
7 Casing B
6 Casing A
2 Kit (Panel Front Sub Assy)
9372579015
9703297113
9372057018
9372059029
9372058015
5 Motor, Induct 9602802012
9372637029
16 Drain Pan S Sub Assy
14 Kit (Panel Right Sub Assy) 9372916025
9372582015
15 Kit (Panel Left Sub Assy)
9 Kit (Panel Rear Sub Assy)
3 Panel Fan Assy
9372581018
9372035009
11 Evaporator Sub Assy 9372584057
9372636022
1 Plate Top Sub Assy 9372576014
Description Parts numberRef.
(Connector : white)
10
10 Room Thermistor 9703299216
