Fujitsu ARTG36LHTB User Manual

SPLIT TYPE
ROOM AIR CONDITIONER
WALL MOUNTED TYPE
Indoor unit Outdoor unit
ASTG30JFCC
ASTG30LFCC
AOTG30JFTC
AOTG30LFTC
CONTENTS
SPECIFICATIONS. . . . . . . . . . . . . . . . . . .1
DIMENSIONS. . . . . . . . . . . . . . . . . . . . . . 2
REFRIGERANT SYSTEM DIAGRAM. . . .3
CIRCUIT DIAGRAM . . . . . . . . . . . . . . . . . 4
ERROR DETECTION . . . . . . . . . . . . . . .
5INDOOR PCB CIRCUIT DIAGRAM. . . . .
8OUTDOOR PCB CIRCUIT DIAGRAM . . .
13
PARTS (INDOOR UNIT) . . . . . . . . . . . . .15
PARTS (OUTDOOR UNIT) . . . . . . . . . . .19
23ACCESSORIES . . . . . . . . . . . . . . . . . . .
