Page #257 background imageLoading...
Page #257 background image
Evaporator Total Assy51
Water Seal53
Evaporator Holder R54
Evaporator Holder L
Parts numberDescriptionRef
9315251015
9314994012
55
Rear Bracket56
57
58
Filter Guide
Filter Guard
52 Connection Pipe Assy
9314995019
9315022011
9315013019
9315411013
59 Pipe Thermistor 9900551018
9315338020
9315355010
59
182012.08.07
INDOOR UNIT
58
56
57
54
52
53
51
55
