Fujitsu ARTG36LHTB - Page 48

INDOOR UNIT
172012.05.28
21
22 Box Shield Assy
Control Box
Terminal
Earth Terminal
23
24 Main PCB (09)
27
Parts numberDescriptionRef
9318228007
9318387001
9318230000
9318211016
28
Cover Shield
25
26
--
Gear Cover
Step Motor 9900139179
29 9316653009
30
Panel Gear
Gear A 9309994003
31 9318232004
32
Display Case
Display PCB 9708365015
9900638009
9318231014
Thermistor Assy 9900563011
9708673110
24 Main PCB (12) 9708673127
21
23
24
31
32
27
29
30
28
25
26
22
