Fujitsu ARTG65LHTA Service Manual

18
16 Power Supply PCB
17 Reactor Assy
Ref. Description
Part number
9710261022
Drain
hose
cover
9900787028
13 Casing A 9381561001
18 Terminal (Remote)
19 Terminal (Power)
9900896003
9900568009
12 Sirocco Fan Assy 9381440016
Pipe
panel
sub assy
20 Heat Sink 9381518005
14 Main PCB 9710016158
15 Communication PCB 9710019005
11 Fan Motor 9603482015
21
Evaporator Total Assy 9374517398
2015.08.17
INDOOR UNIT
ARTG60LDTA
11
14
15
13
12
21
17
20
16
19
11
