Fujitsu ARTG65LHTA Service Manual

2015.09.04
1
TYPE Cooling & Heating
INDOOR UNIT ARTG60LDTA
OUTDOOR UNIT AOTG60LBTA
Capacity 15.8 kW
Capacity
18.0 kW
POWER SOURCE Single phase 240V 50Hz
Rated operating current
20.7 A
Max operating current
Rated operating current
Max operating current
26.0 A
26.0 A
21.0 A
Power consumption
Power consumption
COOLING
4.92 kW
HEATING
4.99 kW
EER
COP
3.21 kW/kW
3.61 kW/kW
Moisture removal
2.1 L/h
COMPRESSOR TYPE
Hermetic rotary type,
2 pole, Single phase,
DC brushless motor
DISCRIMINATION
WEIGHT (with oil)
DA422A3F-28ZAD
REFRIGERANT TYPE
PRECHARGED REFRIGERANT
R410A
4,500 g
23.0 kg
Discrimination
MFG-ZG5KA2P
High 1,070 rpm
INDOOR
UNIT
Medium 960 rpm
FAN MOTOR AND FAN REVOLUTION
AIR CIRCULATION
Quiet
740 rpm
Low 860 rpm
Discrimination MFE-45VVT
Heating
OUTDOOR
UNIT
Upper 900 rpm / Lower 900 rpm
Cooling
Upper 900 rpm / Lower 800 rpm
INDOOR UNIT
OUTDOOR
UNIT
3,700 m
3
/h
3,300 m
3
/h
2,850 m
3
/h
6,850 m
3
/h
7,200 m
3
/h
4,100 m
3
/h
MAX PIPE HEIGHT 30 m
DIMENSIONS
INDOOR UNIT 360 x 1,400 x 850 mm
H x W x D
H x W x D
OUTDOOR UNIT 1,290 x 900 x 330 mm
WEIGHT
INDOOR UNIT
69 kg / 79 kg
Net / Shipping
Net / Shipping
OUTDOOR UNIT
97 kg / 105 kg
ELECTRICAL DATA
SPECIFICATIONS
COMPRESSOR AND REFRIGERANT
Pipe length
30 m 4,500 g
FULL CHARGE
45 m 5,250 g
60 m 6,000 g
75 m 6,750 g
ADDITIONAL CHARGE
50 g/m
NOISE LEVEL
High 44 dB
INDOOR UNIT
Medium 41 dB
Quiet
Cooling
Heating
35 dB
OUTDOOR
UNIT
59 dB
57 dB
Low
High
Medium
Quiet
Cooling
Heating
Low
39 dB
Static pressure : 60Pa
Duct length : Inlet 1m, Outlet 2m

Fujitsu ARTG65LHTA Specifications

General

Brand	Fujitsu
Model	ARTG65LHTA
Category	Air Conditioner
Language	English
