Fujitsu ARTG65LHTA Service Manual

Name and Shape Q’ty Description
Special nut A
(large
4
For suspending the indoor unit
from ceiling
Special nut B
(small
4
Washer
INDOOR UNIT OUTDOOR UNIT
ACCESSORIES
8
Coupler heat insulation (large)
1
For indoor side pipe joint
(gas pipe)
Coupler heat insulation (small)
1
For indoor side pipe joint
(liquid pipe)
Cable tie (large)
4
For fixing the heat insulation
Cable tie (medium)
1
For fixing the remote control cable
Cable tie (small)
1
For fixing the remote control cable
Remote controller
(WDD type)
1
For air conditioner operation
Remote controller accessories
1 set
See Installation manual for
remote control
Drain hose insulation
1
Insulates the drain hose and vinyl hose
Drain hose
1
For installing drain pipe
VP25 (O.D.32, I.D.25)
Hose Band
2015.08.20 16
1 For installing drain hose
Name and shape Q’ty Description
Cable tie with clip
1
For binding power supply cable and
connection cable
Drain pipe
1
For outdoor unit drain piping work
(May not be supplied, depending on
the model.)
Drain cap
2
One-touch bush
2
For power supply cable and
connection cable installation
Parts list for demand control PCB kit
Name and shape Q’ty Description
Cable ties (small)
1
For fixing the EMI core and the signal
transmission cable.
EMI core
1
Attached to the signal transmission
cable.
Insulation
2*
For attaching the EMI core.
One-touch bush
1*
For attaching the signal cable.
(for connecting to the demand
response cable)
* (May not be used, depending on the model.)
