1
6 Pipe Thermistor
Main panel
3 Drain Pan Sub Assy
Intake frame assy
Ref. Description
Part number
9900892005
2 Hose Sub Assy 9378450196
Drain pump panel
Hook metal
9381752010
Service panel
1 Remote Control 9318623048
5
6
5 Room Thermistor
4 Casing B Sub Assy
Intake
angle
9381829019
9703299278
Control box
cover sub assy
2015.08.10
PARTS
INDOOR UNIT
ARTG60LDTA
10
4
2
3
