MULTI TYPE 3-4ROOMS TYPE MULTI TYPE 3-4ROOMS TYPE
BIRD'S-EYE VIEW
[Unit : Inch (mm)]
BRACKETS
BRACKETS
CONTROL BOX
AIR FLOW OUTLET
INSTALLATION PLACE
[Unit : Inch (mm)]
6 (150)
or more
12 (300)
or more
Indoor Unit
Right
side
Left
side
Strong and durable ceiling
MAINTENANCE HOLE
Maintenance hole
Control box
Unit
4 (100)
or more
12 (300)
or more
