3. INDOOR FAN CONTROL
1. Fan speed
( Table 2 : Indoor fan speed table )
*Note, during Economy operation and operation mode is Fan,airflowis 1stepdowns.
(Hi > Me, Me > Lo, Quiet > Soft Quiet)
ASU7RLF1
(rpm)
Poweful
Hi
Me+
Me
Lo
Quiet
Cool Air Prevention
S-Lo
Poweful
Hi
Me
Lo
Quiet
*Soft Quiet
S-Lo
Auto
Operation mode
Heating
Cooling / Fan
Dry
Air flow mode
Fan Speed
1090
1050
1000
950
850
710
600
480
1090
1050
950
850
680
600
480
X, J zone : 680
ASU9RLF1
(rpm)
Poweful
Hi
Me+
Me
Lo
Quiet
Cool Air Prevention
S-Lo
Poweful
Hi
Me
Lo
Quiet
*Soft Quiet
S-Lo
Auto
Operation mode
Heating
Cooling / Fan
Dry
Air flow mode
Fan Speed
1140
1090
1040
980
850
710
600
480
1140
1090
980
850
680
600
480
X, J zone : 680
ASU12RLF1
(rpm)
Poweful
Hi
Me+
Me
Lo
Quiet
Cool Air Prevention
S-Lo
Poweful
Hi
Me
Lo
Quiet
*Soft Quiet
S-Lo
Auto
Operation mode
Heating
Cooling / Fan
Dry
Air flow mode
Fan Speed
1240
1190
1120
1050
910
710
600
480
1240
1190
1050
880
680
600
480
X, J zone : 680
