Fujitsu ARXG12KLLAP Design & Technical Manual

Model: ASYG18KMTE
Outdoor temperature
Indoor temperature (°CDB)
16.0 18.0 20.0 22.0 24.0
(°CDB) (°CWB) TC TC TC TC TC
-15.0 -16.0 4.39 4.29 4.19 4.08 3.98
-10.0 -11.0 5.10 4.98 4.86 4.74 4.62
-5.0 -7.0 5.39 5.26 5.13 5.00 4.87
0.0 -2.0 6.17 6.02 5.87 5.73 5.58
5.0 3.0 7.09 6.92 6.75 6.58 6.41
7.0 6.0 7.09 6.92 6.75 6.58 6.41
10.0 8.0 7.09 6.92 6.75 6.58 6.41
15.0 10.0 7.09 6.92 6.75 6.58 6.41
20.0 15.0 7.09 6.92 6.75 6.58 6.41
24.0 18.0 7.09 6.92 6.75 6.58 6.41
Model: ASYG22KMTE
Outdoor temperature
Indoor temperature (°CDB)
16.0 18.0 20.0 22.0 24.0
(°CDB) (°CWB) TC TC TC TC TC
-15.0 -16.0 5.55 5.41 5.28 5.15 5.02
-10.0 -11.0 6.44 6.29 6.13 5.98 5.83
-5.0 -7.0 6.80 6.64 6.48 6.31 6.15
0.0 -2.0 7.78 7.60 7.41 7.23 7.04
5.0 3.0 8.95 8.73 8.52 8.31 8.09
7.0 6.0 8.95 8.73 8.52 8.31 8.09
10.0 8.0 8.95 8.73 8.52 8.31 8.09
15.0 10.0 8.95 8.73 8.52 8.31 8.09
20.0 15.0 8.95 8.73 8.52 8.31 8.09
24.0 18.0 8.95 8.73 8.52 8.31 8.09
Model: ASYG24KMTE
Outdoor temperature
Indoor temperature (°CDB)
16.0 18.0 20.0 22.0 24.0
(°CDB) (°CWB) TC TC TC TC TC
-15.0 -16.0 6.05 5.90 5.76 5.62 5.47
-10.0 -11.0 7.02 6.86 6.69 6.52 6.35
-5.0 -7.0 7.41 7.24 7.06 6.88 6.71
0.0 -2.0 8.49 8.28 8.08 7.88 7.68
5.0 3.0 9.75 9.52 9.29 9.06 8.83
7.0 6.0 9.75 9.52 9.29 9.06 8.83
10.0 8.0 9.75 9.52 9.29 9.06 8.83
15.0 10.0 9.75 9.52 9.29 9.06 8.83
20.0 15.0 9.75 9.52 9.29 9.06 8.83
24.0 18.0 9.75 9.52 9.29 9.06 8.83
- 522 -
6-3. Heating capacity
6. Capacity table
OUTDOOR UNIT AOYG36KBTA5
OUTDOOR UNIT
AOYG36KBTA5
