Box shield
5 Main PCB (AUXG24KRLB) 9710995873
5 Main PCB (AUXG30KRLB) 9710995880
5 Main PCB (AUXG36KRLB) 9710995897
1 Cable guide
2 Room thermistor Holder
9381376001
9381348008
Ref. Description Part number
3 Room thermistor
4 Pipe Thermistor
9900822002
9900942014
6 Power PCB
7 PCB (Non-polar 2-wire)
9710022005
10 Main PCB holder 9381350001
11 Power PCB Holder 9381349005
9710019005
8 Remote terminal 5P
9 Power Terminal 3P
9900896003
9900720032
2
6
7
5
11
10
1
8
9
3
4
5 Main PCB (AUXG54KRLB) 9710995910
5 Main PCB (AUXG45KRLB) 9710995903
3-1. Models: AUXG36KRLB, AUXG45KRLB, and AUXG54KRLB - (02-6) - 3. Indoor unit parts list
