Item no. Part no. Part name Service part

1 9383880001 Top panel assy ♦

2 9381013005 Protective net ♦

3 9375361013 Net rubber ♦

4 9900984038 Thermistor (Heat exchanger) ♦

5 9900727154 Thermistor assy ♦

6 9383607004 Thermo holder ♦

7 9383874017 Right panel sub assy ♦

8 9383879005 Rear pipe cover ♦

9 9711424013 Inverter PCB ♦

10 9900634025 Reactor assy ♦

11 9901053016 Terminal ♦

9711431097 Main PCB (Service) (for 45 model) ♦

9711431103 Main PCB (Service) (for 54 model) ♦

13 313166024302 Drain cap ♦

14 9303029015 Drain assy ♦

15 9350255009 Base assy (Service) ♦

16 9383876011 Service panel sub assy ♦

17 9383878008 Front pipe cover ♦

18 9351355005 Emblem rear ♦

19 9383863011 Front panel assy ♦

20 9383604003 Blow grille ♦

21 9383689000 Blow grille insulation ♦

22 9383882012 Left panel sub assy ♦

23 9383336003 Propeller fan ♦

24 9603733018 Brushless motor ♦

25 9383862014 Motor bracket assy ♦

26 9374420605 Condenser sub assy ♦

a — Separate wall assy —

b — Control box unit —

3-2. Model: AOYG45KRTA - (02-13) - 3. Outdoor unit parts list
